Advanced charging algorithm
IP67 water and dustproof
Pickup not available
The iTECHDCDC25 keeps your battery charged no matter the battery type or size.
The all-new iTECHDCDC25 charger incorporates an MPPT solar controller allowing charge from solar panels or blankets. When the vehicle runs, the DCDC charger will charge via the alternator; when the vehicle stops, the iTECHDCDC25 will continue charging via your solar panels/blankets (if added).
Exclusive to iTechworld DCDC chargers is a function known as Solar Power Priority (SPP) which represents the preference for solar input. This allows you to set your iTECHDCDC25 to use solar input over the vehicle alternator's input at the push of a button. Solar Power Priority places less load on the alternator, is better for the environment and helps to reduce fuel consumption.
Designed and developed in Australia for Australia, the iTECHDCDC25 is IP67 Waterproof, Dustproof and vibration-proof. Built with a heavy-duty metal case uniquely designed to help with heat dispersion, the iTECHDCDC25 is suited and warranted for under-bonnet installation. Mounting brackets are included in the case design, allowing for easy installation in your setup.
Many vehicles now have smart alternators that do not produce a high enough voltage to charge auxiliary batteries; the iTECHDCDC25 works by enhancing the voltage to the auxiliary battery regardless of the alternator type; the enhancement of voltage is also valuable for overcoming voltage drop from long cable runs to caravans and camper trailers.
A unique feature of the new iTECHDCDC25 is the ability to accept a wide voltage input range from either solar or vehicle input, with the maximum input voltage now being 32v. As the iTECHDCDC25 accepts higher input voltages, it opens the door to 24v inputs as well as some larger voltage solar panels commonly found in residential installations.
The new iTECHDCDC25 is compatible with all battery types but comes into its own when paired with iTechworld lithium batteries. All iTechworld lithium batteries have low voltage protection and will enter "safe mode" to protect themselves when their voltage dips below 10v.
There are various methods to bring an iTechworld lithium battery out of safe mode, but the new iTECHDCDC25 will get an iTechworld lithium battery out of safe mode automatically; if the lithium battery enters safe mode, turn off any load on the battery and the iTECHDCDC25 will take care of the rest, it's that simple.
1 x iTECHDCDC25
6 x Colour coded Anderson Connectors (3 are pre-installed to the iTECHDCDC25)
1 x Instruction manual also found HERE
DCDC25/40 User Guide
Pickup available
Shop risk-free with easy returns.
Shop risk-free with easy returns.
FAQ iTechworld DCDC chargers What battery types does an iTechworld DCDC charger support? An iTechworld DCDC charger supports Lead acid, AGM/GEL, lithium and calcium battery types. Does an iTechworld DCDC charger have a solar input? Yes, an iTechwo...
While other lithium battery brands require you to upgrade your whole charging system (at a considerable extra cost), this is not the case with iTechworld lithium batteries.
When it comes to powering your camping gear or off-road accessories, nothing beats a well-structured 12-volt system. But what exactly is a 12-volt system and how can it enhance your outdoor experience? If you're not an electrical guru, you might ...
The solar priority will not work unless the battery voltage is lower than 13.1v which for a lithium battery would mean that it is less than 50%. Other products by different manufacturers will use solar as the 1st source and top up with the alternator to reduce the load on the alternator which is what is listed on the itech website, but not the case
Had it installed by auto
Electrician works great thank you
Perfect for what I needed
bought with all other itech World battery and monitor works well easy install just need the 150 W solar panel to finish off
I bought the Itech 25 amp dcdc charger because of its water rating as I needed to install it under my camper trailer that I tow with a CanAm spyder,been using Itech products for years and find their products extremely reliable and easy to use
This is the final component in my iTechworld group of 12v products for my hybrid camper. I already have 2 X 120AH lithium batteries, a 40 amp 240v charger and an MPPT solar controller. The DCDC charger was installed to handle the 12v input from the draw bar connection and additional solar input from a solar blanket.
It all fitted together as planned and is working well.
When first installed I had problems with mode selector where it was stuck on STD battery and would not advance to other battery types. After charging for about 5 minutes it suddenly skipped to GEL and finally allowed me to select LITHIUM. With no 12v input the charger has correctly gone into sleep mode and is still indicating LITHIUM. At the time of installing the batteries were at 96% so the delay in selecting the appropriate battery type is a bit of a mystery. Still it all worked out in the end.
One other minor adjustment I made was to swap the black and grey Andersen plugs (as per my photo), All my solar wiring has used black for uncontrolled solar input so I thought it best to continue this on the DCDC charger.
All up it has been a successful exercise.
I wired it up to my 120 Amp Lithium . Easy to install the DcDc good instructions
Easy to connect seams to work fine be great if they had a battery monitor built in.
All hocked up and working well.
