PRODUCT DETAILS
Quick facts about the iTECH160X PRO Lithium Battery:
- Bluetooth compatibility
- Will fit in the space of your old 100Ah batteries
- True drop-in replacement - no need to change chargers or equipment
- IP67 Waterproof - perfect for external mounting
- 160Ah 100% usable capacity
- Only weighs 16 kg (Equivalent AGM weighs approx. 90kg)
- 5 year Australian warranty
- Australian designed and developed
- Australian certified including IEC:62619
AUSTRALIAN DESIGNED & DEVELOPED
The iTECH160X PRO lithium battery sets a new standard. It has been specifically engineered for those seeking a power solution that can withstand whatever you throw at it.
Designed and developed in Australia, for Australia, the iTECH160X PRO has been constructed to thrive in rough climates and conditions – and thanks to its IP67 water and dust-proof rating, it can be mounted nearly anywhere!
RUGGED DURABILITY
The iTECH160X PRO uses A-grade prismatic lithium LiFePO4 cells, which offer considerable advantages over other cell types. Prismatic cells are thinner in profile, deliver higher discharge, have a longer life expectancy, are much lighter and utilise space more efficiently than traditional cell types.
The advanced lithium technology offers a 100% useable 160Ah capacity, allowing for impressive power storage. Not to mention the minute weight of 16kg, which is comparison to an equivalent AGM battery would be 90kg, saving you and your system important weight.
DROP IN REPLACEMENT
No need to change any systems, equipment, or do any re-wiring. With the iTECH160X PRO, you simply pull out your old heavy AGM batteries, and drop-in your new iTECH160X PRO.
The iTECH160X PRO has been designed and developed to fit the same space as the standard 100Ah AGM batteries so it is a simple drop in replacement for your system, reading dimensions of 330x173x215mm (230mm including terminals).
BLUETOOTH COMPATIBILITY
Never second-guess your battery’s health again! The iTECH160X PRO is integrated with full Bluetooth compatibility, allowing you to monitor your battery’s status in real-time via the iTechworld Connect Battery Management app, available through the App Store or the Google Play Store.
You can check your battery’s vitals in real-time and rest easy knowing that it is Australian-certified to IEC:62619 standards.
PACKAGE CONTENTS
- 1 x iTECH160X 160Ah Lithium 12V Battery
- 1 x Instruction Manual
WARRANTY & SUPPORT
The iTECH160X warranty is 5 years (3 years full replacement, 2 years pro-rata).
If your iTechworld battery enters Safe Mode, please follow the instructions HERE
*Storage deep cycle battery only. It cannot be used as a cranking battery.
Specifications
Nominal Voltage: | 12.8V |
C20 Rating usable amps 10v: | 160Ah |
Short Circuit Protection: | Yes |
Optimum Temperature Range: | +5 to +60°C |
BMS Operational Temperature Range: | -5 to 80°C |
Safety Protection Isolator: | 80°C |
Recommended Charge Current: | 1 - 60A |
Maximum Charge Current: |
100A |
Recommended Charge Voltage: | 14.4V |
BMS Charge Cut-Off Voltage: | 15V |
BMS Low Voltage Cut Off: | 8.5 - 9V |
Continuous Discharge: | 150A (175A 5 mins) |
Peak Discharge: | 270A 5 secs |
Series Connection: | Up to 48V (4 x batteries) |
Parallel Connection: | Unlimited |
Life Cycles 100%: | 5000 |
Life Cycles 50%: | 10000 |
Dimensions (LxWxH): | 330x173x215mm (230mm including terminals) |
Weight: | 16Kg |
Terminal Type: | M8 |
Case Material: | ABS |
Safety Certifications: |
|
UL Certified 1642 | |
CE Certified | |
IP67 Rated | |
Rohs Certified | |
UN38.3 Certified | |
ISO 9001 Certified | |
ISO 1400 Certified | |
IEC:62619 Certified |
