iTECH024 24Ah 12V Lithium-ion Battery LiFePO4

We are introducing our latest lithium battery, the iTECH024. The iTECH024 LiFePO4 lithium battery is the perfect drop-in replacement battery for a motorised golf buggy. iTECH024 can operate at 12v, 24v, 36v and even 48v through series connection.

BMS/OPERATING SYSTEM: 100% of the iTECH024's capacity is usable. The internal BMS allows 25A continuous discharge. The iTECH024's internal BMS controls cell balancing, over and under-voltage protection, short circuit protection, thermal protection, and has over-discharge protection (safe mode).

CAPACITY: The iTECH024 24Ah Lithium-ion is the equivalent to 48Ah in lead-acid batteries (based on the standard depth of discharge of the iTECH024 (100%) and lead-acid battery (50%).

WEIGHT: The iTECH024 weighs just 2.8kg the equivalent lead-acid battery weighs 13+kg.

USE MOST CHARGERS: The iTECH024 will charge up to 5x faster than lead-acid batteries. The iTECH024 can charge from just about all existing chargers with no extensive modifications required to existing systems.

LIFE SPAN: The iTECH024 can cycle up to 5000 times at 50% depth of discharge. A lead-acid equivalent can cycle up to 500 times at a 50% depth of discharge. The iTECH024 has little to no self-discharge rate (≤2%), the battery can sit for long periods and will not go flat.

AUSTRALIAN: Designed and developed in Australia for use with caravans, camper trailers, motor homes, 4WD, boats, yachts, trucks, golf buggies and everything in-between. The iTECH024 will operate flawlessly in extreme heat and will handle heavy vibrations usually associated with corrugated roads.

FEATURES:

Heavy duty case

Can be connected in parallel (up to 4)

Can be connected in series (up to 4)

High discharge current max 48A (5sec)

Heavy-duty removable M5 Bolt Battery terminals

Maintenance-free

Lithium-ion LiFePO4

Inbuilt battery management system

Redback™️ Lithium Operating System installed as standard.

Built-in over-discharge protection.

SPECIFICATIONS:

Charging Voltage: 14.4 to 14.7v

Standard discharge current: 24A

Max discharge current: 48A (5sec)

Standard charge current: 12A

Maximum charge current: 24A

Output connector: M5 Stud

Waterproof to IP65.

Dimensions: 180x80x170mm (LxWxH)

Optimal charge temp range: 0°c to + 45°c

Optimal discharge temp range: -20°c to + 60°c

Optimal storage temp: -10°c to + 45°c

Weight: 2.8kg each

PACKAGE CONTENTS:

1x Lithium Battery iTECH024

Pre-installed Redback™️ Lithium Operating System

If your iTechworld battery enters safe mode, please follow the instructions HERE

The statutory warranty is 36 months from the date of purchase.

Storage deep cycle battery only. It is not a cranking battery.
