iTECH200SS
Super Slim Deep Cycle Lithium Battery
with Bluetooth LiFePO4 200Ah
-
Super slim at 126mm wide
-
Bluetooth BMS
- Regular price
- $1,199
- Sale price
- $1,199
- Regular price
-
$1,699
Tax included.
Shipping calculated at checkout.
29% OFF
or 4 x $299.75
Australian Family Owned
Established in 2006, powering Aussies since.
LEGENDARY SUPPORT
Need help? Speak to an Aussie Power Expert.
Need Help Deciding?
Pickup not available
Product Features
Overview
The new and improved iTECH200SS 200Ah Super Slim Lithium Battery is small but packs a punch! Measuring at only 126mm wide and weighing in at 25.5kg, our 200Ah battery has been designed to be the ultimate Super Slim battery for small spaces that still need maximum power. Designed and developed in Australia, the new iTECH200SS Slimline Battery is suited to thrive in our harsh Australian conditions, with 100% usable capacity, Bluetooth monitoring, dust-proof, suitable for high heat conditions, certified to IEC 62619 and backed by a 5-year Aussie warranty.
Never guess your batteries health again. The iTECH200SS Lithium Battery now comes integrated with Bluetooth compatibility to monitor your battery's status via the iTechworld app. Download the iTechworld app on the App Store or Google Play Store.
With a 100% useable capacity, our 200Ah battery features the latest in prismatic cell technology allowing for its small form factor and lightweight nature.
iTechworld has been designing and developing Lithium Batteries for over 10 years, constantly improving and testing our designs. The iTechworld Lithium Batteries are Australian standard certified to IEC:62619 to create the safest and highest-quality lithium batteries available in the Australian market.
The new and improved iTECH200SS 200Ah Super Slim Lithium Battery is small but packs a punch! Measuring at only 126mm wide and weighing in at 25.5kg, our 200Ah battery has been designed to be the ultimate Super Slim battery for small spaces that still need maximum power. Designed and developed in Australia, the new iTECH200SS Slimline Battery is suited to thrive in our harsh Australian conditions, with 100% usable capacity, Bluetooth monitoring, dust-proof, suitable for high heat conditions, certified to IEC 62619 and backed by a 5-year Aussie warranty.
Never guess your batteries health again. The iTECH200SS Lithium Battery now comes integrated with Bluetooth compatibility to monitor your battery's status via the iTechworld app. Download the iTechworld app on the App Store or Google Play Store.
With a 100% useable capacity, our 200Ah battery features the latest in prismatic cell technology allowing for its small form factor and lightweight nature.
iTechworld has been designing and developing Lithium Batteries for over 10 years, constantly improving and testing our designs. The iTechworld Lithium Batteries are Australian standard certified to IEC:62619 to create the safest and highest-quality lithium batteries available in the Australian market.
Designed to be a true drop-in replacement for existing systems, the iTECH200SS is the ideal choice for those wanting to upgrade their current sleepy AGM or lead-acid systems to lightweight lithium technology. With the iTECH200SS, simply pull out your old AGM or lead-acid batteries and drop in the iTECH200SS Lithium Battery. It's really that simple!
What sets the iTECH200SS apart is its dual-terminal design, with positive and negative posts on both sides of the battery. This enables easy installation in space-restricted setups and supports high-current applications, such as 3000W inverters or multi-battery parallel configurations.
Utilising A-grade prismatic lithium LiFePO4 cells, our 200Ah battery offers drastic advantages over other cell types. Prismatic cells are thin in profile, deliver higher discharge, have a longer life expectancy, are extraordinarily light and utilise a more effective use of space.
PACKAGE CONTENTS
WARRANTY & SUPPORT
The iTECH200SS warranty is 5 years (3 years full replacement 2 years pro-rata).
*Storage deep cycle battery only. It cannot be used as a cranking battery.
If your iTechworld battery enters safe mode, please follow the instructions HERE
Product Info
- Maximum Discharge Rate (5 seconds)640 amps
- Prismatic Cell Technology10,000+ cycles @ 40% DoD
- Warranty5 year Australian Warranty
- Super slimAt only 126mm wide
- Lightweight at 25.5kgEquivalent AGM weighs approx. 140kg
| General | |
|---|---|
| Voltage: | 12V |
| Nominal voltage: | 12.8V |
| C20 rating usable capacity: | 200Ah |
| Short circuit protection: | Yes |
| Optimum temperature range: | 5°C ~ 60°C |
| BMS operational temperature range: | -40°C ~ 80°C |
| Safety protection isolator: | 80°C |
| Recommended charge voltage: | 14.4V |
| Maximum charge current: | 150A |
| BMS charge cutoff: | 15V |
| BMS low voltage cutoff: | 8.5-9V |
| Series connection: | Up to 48V (4 x batteries) |
| Parallel connection: | Unlimited |
| Life cycles @ 80% depth of discharge: | 5,000+ |
| Life cycles @ 40% depth of discharge: | 10,000+ |
| Continuous Discharge Rate: | 200A |
| Maximum Discharge Rate (5 Seconds): | 640A |
| Dimensions (LxWxH): | 514 x 327 x 126mm (580 L with brackets and 350 H including terminals) |
| Weight: | 25.5kg |
| Terminal type: | M8 |
| Case material: | Stainless steel |
- Length (with brackets): 580mm
- Length (without brackets): 514mm
- Width: 126mm
- Height (with brackets): 350mm
- Height (without brackets): 327mm
Frequently Asked Questions about the iTECH200SS Super Slim Deep Cycle Lithium Battery with Bluetooth LiFePO4 200Ah
How does the Bluetooth monitoring feature of the iTECH200SS enhance battery management for users in remote areas?
Can the iTECH200SS be mounted in any orientation, or does it require specific positioning for optimal performance?
What are the benefits of the dual-terminal design in high-current applications for this 200Ah battery?
How does the prismatic cell technology used in the iTECH200SS compare to cylindrical or pouch cell technologies in terms of performance and longevity?
How does our 200Ah battery perform in extremely cold conditions, given its BMS operational temperature range?
What considerations should be taken into account when connecting the iTECH200SS in a parallel configuration with other batteries?
How does the iTECH200SS manage energy efficiency when used continuously with high-power inverters up to 3000W?
What impact does the stainless steel case material have on the durability and safety of the iTECH200SS in rugged environments?
Are there specific advantages of a 200Ah battery in 4WD and canopy setups compared to other battery types?
How does the iTECH200SS ensure safety during overcharge or short circuit scenarios, especially in high-temperature conditions?
Can the iTECH200SS be integrated with solar charging systems, and are there specific recommendations for optimizing this setup?
- Slimline Batteriers User Guide Download
