AUSTRALIAN DESIGN AND DEVELOPMENT
iTechworld is proud to present the 200W 22V Hard Frame Solar Panel – designed and developed in Australia, for Australia. These panels utilise advanced HPX PRO technology that offers unparalleled efficiency and durability. These panels also come with an IP67 waterproof rating to withstand the rigours of the Australian outback. At just 17mm thick, the 200W 22V Hard Frame panel is lighter than conventional panels.
POWER FROM ANYWHERE
The benefit of a solar panel is that you can access power wherever you can access the sun! The 200W 22V Hard Frame Solar Panel has been constructed robustly to withstand the Aussie outback. This ensures that you can mount your panel anywhere and power up your devices no matter where you're parked—keeping you off-grid for longer!
SECURE AND STABLE
The 200W 22V Hard Frame Solar Panel can be mounted on your car, caravan or even your boat, utilising our custom-made mounting brackets (coming soon!). Its design ensures optimal energy absorption, keeping your system powered no matter what adventure you’re on.
MOUNTING BRACKETS (Sold Separately):
To help secure your solar panels, we offer easy-to-use mounting brackets, sold separately. These brackets are designed for hassle-free installation, ensuring your solar panels are securely mounted on your caravan or 4WD.
Click here to purchase the mounting brackets.
Package Contents
- 1 x 200W 22V Hard Frame Solar Panel
Support
The statutory warranty is 12 months from the date of purchase.
SPECIFICATIONS
Dimensions (LxWXH) |
1460x670x17mm |
Weight: |
10kg |
Max Wattage: |
200W |
Max Voltage: |
18.1V |
Open-Circuit Voltage(Voc) |
22V |
Short-Circuit Current(|sc) |
12.2A |
Normal Operating Cell Temp(NOCT) |
45+2°C |
Maximum System Voltage |
1000VDC |
Maximum Series Fuse Rating |
15A |
Operating Temperature |
-40 C ~ 85 C |
Cable Length: |
85cm |
Weight |
9.32KG |
All technical data is provided under standard test conditions: E=1000/M2, TC=25°C, AM=1.5
